Ближньопольовий відкритий коаксіальний сенсор. Оцінка просторової роздільної здатності вимірювальної апертури


Анотація

Мікрохвильові сенсори знаходять все більш широке використання в різних галузях. Сенсори стають все більш складними, методи їх опису стають все більш прецизійними. У роботі наведена спрощена модель опису ближнього поля коаксіального сенсора. Надані обгрунтування спрощення аналітичного рішення, розглянуті компоненти поля в робочій області і проаналізовано розподіл поля в робочій області. Показані результати порівняння розподілів компонент електромагнітного поля поблизу апертури, отримані на підставі суворої і спрощеної моделей. Проникнення поля у зразок у першому наближенні відповідає радіальному розподілу. Просторова роздільна здатність сенсора, як по радіусу, так і по глибині зразка визначається діаметром центрального провідника або розміром щілини. Варіюючи форму апертури можна змінювати характеристики сенсора, оптимально підбираючи їх під апріорно відомі властивості зразків.
